Sheet bending machine parts
Year 06/2010
Machine hours: about 36.000h
Description
The „PLUS“ version contains a higher automation level
- automatic tool changer
- automatic gripper change
- Loading and unloading robot ASTRO-MP 20 linear movable on 2500 mm axis
- transfer table ABT with automatic adjustment
Press brake Amada HDS-1030 NT
Press force 1000 kN
Drive Servo hydraulic
Deflection compensation active hydraulic cylinder
Bending length 3000 mm
Distance between frames 2700 mm
Throat 415 mm
Stroke 200 mm
Installation height 500 mm
Working area backgauge 600 mm
Width of working table 60 mm
Number of controlled axis 7
Approach/return speed 200 mm/s
Bending speed 20 mm/s
Power consumption 7,6 kVA
Oil volume 57 l
Weight 6.700 kg
Control AMADA AMNC II
Loading and unloading robot ASTRO-MP 20
Max. capacity (incl. gripper) 20 kg
Number of controlled axis 6
Max. workpiece dimension as ASTRO-100 NT
Stack height raw material 500 mm
Drive AC-Servomotor
Control Amada AMNC II – AS100CE
Bending robot ASTRO-100 NT
Control Amada AMNC II – AS100CE
Max. capacity (incl. gripper) 20 kg
Number of controlled axis 5
Length of linear axis 3080 mm
Max. sheet thickness 2,5 mm
Max. workpiece size 800 x 1000 mm
Max. workpiece size as profile 300 x 1800 mm
Repeat accuracy +/- 0,1 mm
Drive AC-Servomotor
Weight 450 kg
Baujahr 06/2010
Maschinenstunden: ca. 36.000h
Beschreibung
Die „PLUS“ Version beinhaltet einen höheren Automatisierungsgrad durch
- automatischen Werkzeugwechsler
- automatischer Greiferwechsel
- Be- und Entladeroboter ASTRO-MP 20 linear verfahrbar auf 2500 mm Achse
- Transfertisch ABT mit automatischer Verstellung
Abkantpresse Amada HDS-1030 NT
Presskraft 1000 kN
Antrieb Servo-hydraulisch
Durchbiegekompensation aktive Hydraulikzylinder
Abkantlänge 3000 mm
Durchgang zwischen den Maschinenständern 2700 mm
Ausladung 415 mm
Hub 200 mm
Einbauhöhe 500 mm
Verstellbereich Hinteranschlag 600 mm
Breite des Arbeitstisches 60 mm
Anzahl gesteuerter Achsen 7
Geschwindigkeit Zustellen/ Rückhub 200 mm/s
Geschwindigkeit max. Arbeit 20 mm/s
Anschlussleistung 7,6 kVA
Ölvolumen 57 l
Gewicht 6.700 kg
Steuerung AMADA AMNC II
Be- und Entladeroboter ASTRO-MP 20
Max. Kapazität (inkl. Greifer) 20 kg
Anzahl der gesteuerten Achsen 6
Max. Werkstückabmessung wie ASTRO-100 NT
Stapelhöhe Rohmaterial 500 mm
Antrieb AC-Servomotor
Steuerung Amada AMNC II – AS100CE
Abkantroboter ASTRO-100 NT
Steuerung Amada AMNC II – AS100CE
Max. Kapazität (inkl. Greifer) 20 kg
Anzahl gesteuerter Achsen 5
Länge der Linearachse 3080 mm
Max. Blechdicke 2,5 mm
Max. Zuschnittgröße 800 x 1000 mm
Max. Zuschnittgröße als Profil 300 x 1800 mm
Wiederholgenauigkeit +/- 0,1 mm
Antrieb AC-Servomotor
Gewicht 450 kg
